Vector oogstband

Vector harvesting beltQuick filling into big boxes

Vector harvesting belt

The Vector harvesting belt is equipped with a small conveyor at the end of the harvesting belt. This conveyor is positioned in the center of four boxes and has the ability to rotate and change direction. The crops that are placed on the harvesting belt will fall on this conveyor and this conveyor will put it then in the boxes that are placed directly underneath. Since the harvesting belt can be constructed up to 15meters, it is suitable to be used while driving in the fixed roads in the field. The first four meters of the flat part in the field is foldable, this makes it more compact during transport and storage.

Vector harvesting belt
specs
  • Length: up to 15 meters
  • Width: 27cm/37cm/47cm or 57cm
  • Stepless adjustable speed
  • Fallbreakers
  • Practical capacity of 8.000 pieces/hour
  • 4 meter semi-automatic foldable
  • Automatic belt tensioners
  • Long lasting hydraulic drive drums
  • Unique self supporting construction, from 275kg
  • Plug-and-play on your tractor
  • CE-marked
  • Designed for your equipment
productsheethttps://www.beetsaluminium.eu/library/general/1684315147.5666.pdf

add-ons

Adjustable support
Adjustable support

The support is hydraulically adjustable to quickly compensate level changes in the field

Mount and move system
Mount and move system

Grooved aluminium wheels allows you to mount the harvesting belt to the trailer and roll it from front to the back

LED-Lights
LED-Lights

LED-lights on the flat part in the field shine direct light on the crop to improve sight during dark hours

Wheels
Wheels

Eases transport in the field and optimises the mounting process to the harvesting trailer

Radio
Radio

The 12V bluetooth radio is integrated in the frame of the harvesting belt and connected to two integrated speakers

High sides
High sides

High sides prevent that the crops fall off from the belt and are available in different heights

Side belt
Side belt

A flat belt is mounted horizontally next to the inclining part of the harvesting belt, it ensures full-length harvesting ability

fall breaker
fall breaker

Elektro hydraulically operated fall breakers on both sides of the dump belt

compatible with

swipe gesture

video

Why using the Vector harvesting belt?8 reasons to use the Vector harvesting belt
  • No soil compaction, fixed roads in the field
  • 60% more efficiency during harvesting
  • Eliminates movements to the harvesting trailer
  • Extremely short set-up times
  • Fall breakers
  • Practical capacity of 8.000 pieces/hour
  • Plug-and-play on existing equipment
  • No people inside the trailer
